Geometric and Engineering Drawing

Spread The Love By Sharing This..!!

Geometric and Engineering Drawing

Pages: 360

Table of contents:

Part 1 Geometric Drawing 1
1 Scales 3
2 The Construction of Geometric Figures from Given Data 11
The Triangle 14

3 Isometric Projection 31
4 The Construction of Circles to Satisfy Given Conditions 43
5 Tangency 59

6 Oblique Projection 67
7 Enlarging and Reducing Plane Figures and Equivalent Areas 75

8 The Blending of Lines and Curves 91
9 Loci 103

10 Orthographic Projection (First Angle and Third Angle) 117
11 Conic Sections – the Ellipse, the Parabola, the Hyperbola 149
12 Intersection of Regular Solids 165

13 Further Orthographic Projection 185
14 Developments 201
15 Further Problems in Loci 221

16 Freehand Sketching 235
17 Some More Problems Solved by Drawing 245

Part 2 Engineering Drawing 263
18 Engineering Drawing 265
Introduction 265
Type of Projection 265
Sections 266

Screw Threads 272
Dimensioning 279
Conventional Representations 284
Abbreviations 289

Framing and Title Block 290
Assembly Drawings 294
Some Engineering Fastenings 294
Three Worked Examples 301
