Star and delta connections are two common methods used in electrical systems to connect three-phase AC devices.

1. Configuration:

• Star (Wye) Connection: In this configuration, the three phases are connected at a common point, forming a star or wye shape. This common point is often grounded.
• Delta (Mesh) Connection: In this configuration, the three phases form a closed loop, resembling a delta or triangle. There is no common point.

1. Voltage Relationship:

• Star Connection: The line voltage (VL) is equal to the phase voltage (VPh). The line current (IL) is √3 times the phase current (IPh).
• Delta Connection: The line voltage (VL) is √3 times the phase voltage (VPh). The line current (IL) is equal to the phase current (IPh).

1. Impedance Transformation:

• Star Connection: Each phase impedance is the same as the line impedance.
• Delta Connection: Each phase impedance is √3 times the line impedance.

1. Application:

• Star Connection: Commonly used in power distribution systems and for devices requiring a neutral connection.
• Delta Connection: Often used in high-power applications where a neutral connection is not needed, such as motors.

1. Advantages and Disadvantages:

• Star Connection: Provides a neutral point, suitable for single-phase loads. Balanced loads are easier to achieve. However, the line current is higher than in a delta connection for the same power.
• Delta Connection: No need for a neutral wire. The line current is lower than in a star connection for the same power. However, it lacks a neutral point and can be more challenging to balance.

Choosing between star and delta connections depends on the specific requirements of the electrical system and the devices connected to it.
